The UMG 509 PRO is a powerful grid analyser with colour-graphic display and intuitive user interface. Residual current monitoring and comprehensive range of protocols for simple integration into existing communication architectures. The grid analyser measures with an accuracy of 0.2%. The UMG 509 PRO meter can also be connected to LoRaWAN networks over Pulse or ModBus LoRa interfaces. Free network visualisation software GridVis®-Basic.
Features
- Panel mounted
- Simple integration into the LVD board
- Ethernet interface and web server
- Harmonics analysis up to 63rd harmonic
- Display of waveforms (current and voltage)
- Logging and storage of transients (> 50 μs)
- Ethernet & RS485 Port ModBus RTU
- Option BACnet communication
- ModBus IP Gateway
- Master – Slave Configuration
- MID certified
- Comprehensive programming options on the device
- PLC functionality
- Complete APPs from the Janitza library
